bar bending schedule-an ovwrview




Reinforcement Bar Schedule

Reinforcement Bar Schedule is prepared in a standard manner. The bar bending schedule should be prepared and it should be submitted to the steel bar steel yard to cut and to bend the bars for purposes, because bar bending schedule is the simplest of details what is in the drawings which can easy to under stand for bar benders. It contains all the details needed for fabrication of steel.Those details are bar mark, bar type and size, number of units, length of a bar, shape code, distance between stirrups (column, plinth, beam) etc.

Advantages of the Bar Schedule:

  • By preparing a bar schedule, and arranging them according to the lengths, it will lead to an economical bar cutting, reduce the bar cutting wastages.
  • It is easy to manage the reinforcement stock required for identified time duration.
  • It will help to fabrication of R/F with structure.
in this note i try to explain the following things

Weight per meter length ,weight of full length of different diameter rebar’s and number of full lengthy required for 01 metric tone
Reinforcement Steel types:
steel field test
TERMS RELATING TO STEEL DETAILING
Bar bending schedule format/Performa:
Procedure for carrying out Bar bending Schedule
Instance of RCC Beam Reinforcement Calculation
No. of stirrups required for given beam
CODES, SPECIFICATIONS & STANDARDS
excersises

and many more
